1.0mm RAL 1030 Prepainted Steel Sheet DX51D 1250mm Width for Roofing and Wall Cladding

1.0mm RAL 1030 Prepainted Steel Sheet DX51D 1250mm Width for Roofing and Wall Cladding

1．Product Overview

1.0mm RAL 1030 prepainted steel sheet is designed for roofing sheets, wall cladding panels, steel structure buildings, and exterior architectural applications requiring stable color appearance and outdoor durability.

The product combines hot dipped galvanized steel or galvalume steel substrate with a continuous coating process. The painted surface improves corrosion resistance, UV durability, and appearance consistency for long-term exterior use.

2．Technical Solution

The steel sheet uses galvanized or galvalume substrate together with primer and finish coating layers.

Available coating systems include PE, SMP, and PVDF. PE coating is suitable for standard roofing and wall applications. SMP coating improves weather resistance for outdoor exposure. PVDF coating provides stronger UV resistance and improved long-term color stability.

The standard coating structure uses 25±5 micron top coating and 7±2 micron back coating to maintain coating consistency and stable forming performance.

3．Specifications

4．Application

This prepainted steel sheet is suitable for roofing sheets, wall cladding panels, steel structure workshops, warehouses, airport buildings, storage facilities, prefabricated buildings, shipbuilding panels, vehicle panels, and decorative construction applications.

It is commonly used where the finished product requires stable color consistency, corrosion resistance, and reliable forming performance.

5．Processing

• The material can be supplied in coil form or processed into cut-to-length sheets.
• It is suitable for roll forming, bending, profiling, roofing sheet production, and wall cladding fabrication.
• Protective film can be applied on the top side to reduce surface scratches during transportation and installation.
• Custom slitting and cut-to-length processing are available according to project requirements.

6．Advantages

• The galvanized or galvalume substrate provides reliable corrosion resistance for outdoor construction applications.
• The 0.12–1.00mm thickness range supports mainstream roofing and wall panel production requirements.
• The 700–1250mm width range is compatible with common roll-forming equipment.
• PE, SMP, and PVDF coating systems support different outdoor exposure conditions.
• PVDF coating provides improved UV resistance and long-term weatherability.
• Customized RAL colors support architectural appearance consistency and project matching requirements.

7．How to Choose

• Choose PE coating for standard roofing sheets and wall panels.
• Choose SMP coating when improved weather resistance is required.
• Choose PVDF coating for stronger UV resistance and long-term exterior durability.
• Choose galvanized substrate for general construction applications.
• Choose galvalume substrate for projects requiring improved heat reflectivity and corrosion resistance.
• Confirm coating type, color, gloss level, protective film, and processing requirements before production.

8．FAQ

Q1．What coating systems are available
PE, SMP, and PVDF coating systems are available.

Q2．Can customized RAL colors be supplied
Yes. Customized RAL colors can be produced according to project requirements.

Q3．What is the available thickness range
The available thickness range is 0.12–1.00mm.

Q4．Is the product suitable for roofing sheet production
Yes. The material is suitable for roofing sheets, wall cladding panels, and roll-formed building products.

Q5．Can protective film be applied
Yes. Protective film can be applied on the top side when required.
