Customized Pre-Painted Corrugated Steel Roof Sheets for Building Decoration and Roofing Panels

Customized Pre-Painted Corrugated Steel Roof Sheets for Building Decoration and Roofing Panels

1．Product Overview

Customized pre-painted corrugated steel roof sheets are used for roofing, wall cladding, building decoration, steel structure buildings, workshops, warehouses, and light construction panels.

The product uses hot dipped galvalume steel as the base metal with a color-coated surface. The AZ coating provides substrate protection, while the painted surface supports color consistency and exterior appearance. The corrugated profile improves panel rigidity and water drainage performance for roofing applications.

2．Technical Solution

The material is produced from galvalume steel substrate according to JIS G3322, ASTM A792, and EN 10169. The AZ coating range is 20–180g/m².

The top surface uses 10–20 micron polyester plus 5 micron primer. The back surface uses 5–7 micron or 7–8 micron polyester plus 5 micron primer.

Available paint systems include polyester, SMP, and PVDF. Polyester is suitable for standard building use, SMP is selected when better weather resistance is required, and PVDF is used for higher UV exposure and longer exterior service.

3．Specifications

4．Application

This product is suitable for roofing sheets, wall cladding, building decoration, steel structure workshops, warehouses, industrial buildings, commercial buildings, prefabricated buildings, and home appliance panels.

It is commonly used where the final panel requires corrosion protection, stable color appearance, lightweight installation, and formed sheet rigidity.

5．Processing

• Sheets can be supplied according to required project length.
• Different effective widths and corrugated profiles can be arranged according to roofing layout.
• The product supports cutting, stacking, bundling, and export packing.
• Customized RAL colors can be produced according to project requirements.

6．Advantages

• The galvalume substrate provides reliable corrosion protection for roofing and wall panels.
• The 0.12–1.50mm thickness range covers common roofing and cladding applications.
• The 800–900mm effective width options support standard roofing installation layouts.
• The 20–180g/m² AZ coating range allows selection for different service environments.
• The corrugated profile improves sheet rigidity and roof drainage performance.
• Polyester, SMP, and PVDF paint systems support different weather resistance requirements.

7．How to Choose

• Choose polyester coating for standard roofing and wall cladding projects.
• Choose SMP coating when better weather resistance is required.
• Choose PVDF coating for high UV exposure or longer exterior service.
• Choose higher AZ coating levels for humid, coastal, or more exposed environments.
• Choose sheet thickness according to roof span, wind load, and required panel rigidity.
• Confirm effective width, length, wave profile, color, and packing method before production.

8．FAQ

Q1．What is this product used for
It is used for roofing sheets, wall cladding, building decoration, workshops, warehouses, and light construction panels.

Q2．What is the available thickness range
The available thickness range is 0.12–1.50mm.

Q3．Can customized colors be supplied
Yes. Colors can be supplied according to RAL Card or client request.

Q4．What paint systems are available
Polyester, SMP, and PVDF paint systems are available.

Q5．Can the wave profile be customized
Yes. Wave width and wave height can be customized according to project requirements.
