    Product Details:

    Place of Origin: China
    Brand Name: Huaye
    Certification: ISO14000

    Payment & Shipping Terms:

    Minimum Order Quantity: 50MT
    Packaging Details: Standard export packing
    Delivery Time: 45 days
    Payment Terms: L/C, T/T
    Supply Ability: 10000MT
    Contact Now
    Detailed Product Description
    Steel Grade: CGCC, DX51D+Z Thickness: 0.15mm To 0.80mm
    Effective Width: 820mm/880mm/900mm Etc Length: 1600 To 4500 Mm
    Zinc Coating: 80 To 275 GSM Crest: 16.5mm
    Pitch: 76.2mm Color: White, Red, Blue Or Customized As Per RAL Color Card

    Customized color CGCC, DX51D Z adornment PRE-PAINTED CORRUGATED ROOFING SHEET



    Steel Grade: CGCC, DX51D+Z

    Thickness: 0.15mm to 0.80mm

    Effective width: 820mm/880mm/900mm etc.

    Length: 1600 to 4500 mm

    Zinc Coating: 80 to 275 GSM

    Crest: 16.5mm

    Pitch: 76.2mm

    Color: white, red, blue or customized as per RAL color card

    Main application:Roofing, metope adornment, various internal

    and external pack material, suitable for the requirement of any building



    Specifications:

    Baseplate PRE-PAINTED CORRUGATED ROOFING SHEET
    Thickness 0.15-0.8mm
    Width 600-1250mm
    Coil ID 508mm/610mm
    Coil Weight 3-8MT
    Paint Material PE,SMP,HDP,PVDF
    Coated Type 2/1,2/1M,2/2
    Color Option As per RAL No./Customer Sample
    Packing Standard export packages





    Application:

    Using hot galvanized sheet and zinciron alloy hot galvanized sheet as the substrate, color coated sheet is made by first going through surface pretreatment, then the coating of one or more layers of liquid coating by roll coating, and finally baking and cooling. The coatings used including polyester ,silicon modified polyester, highdurability polyester, polyvinylidene fluoride,epoxy and high corrosionresisting coatings have good durability, corrosionresistance and formability. Color coated sheet is widely used in building, Transport, home appliances, solar energy,furniture, etc. In home appliances, it is mainly used as the side door plate of refrigerators,and shell of DVDs, air conditions,freezers,and washing machines.



    Corrugated Galvanized Sheet is mainly used as roof and wall for industrial buildings and portable houses.



    Our prodocts are widely used in power plants.electrical equipment company,car showrooms,steel plant, cement warehouse,steel structure office.airport teminals,train stations,stations,stadiums,concent halls,theaters.supermarkets.logistics center, the Olympic sports atadiums and other venues steel wall systems and roofing system construction.





    customized color CGCC, DX51D Z adornment Pre painted Corrugated steel Roof Sheets / Sheet



    customized color CGCC, DX51D Z adornment Pre painted Corrugated steel Roof Sheets / Sheet
