Lightweight Color Coated Corrugated Sheet Metal Panels for Roofing and Wall Cladding

Lightweight Color Coated Corrugated Sheet Metal Panels for Roofing and Wall Cladding

1．Product Overview

Lightweight corrugated sheet metal panels are designed for roofing, wall cladding, industrial buildings, warehouses, workshops, container panels, and general construction applications.

The product uses hot dipped galvalume steel substrate with color coating and corrugated forming. The lightweight structure supports easier handling and installation, while the corrugated profile improves panel rigidity and roof drainage performance.

2．Technical Solution

The panels are manufactured from CGLCC or DX51D+AZ galvalume steel according to JIS G3322, ASTM A792, and EN 10169 standards.

The AZ coating range from 50–180g/m² provides corrosion protection for outdoor use. The coating system includes 15–20 micron polyester plus 5 micron primer on the top surface, and 5–7 micron or 7–8 micron polyester plus 5 micron primer on the back surface.

Available paint systems include PE, SMP, PVC, and PVDF for different weather exposure and durability requirements.

3．Specifications

4．Application

The product is suitable for roofing systems, wall cladding, industrial buildings, commercial buildings, warehouses, workshops, container panels, prefabricated buildings, and home appliance exterior applications.

It is widely used in projects requiring lightweight installation, corrosion resistance, and customized architectural appearance.

5．Processing

• Sheets are produced through continuous color coating and corrugated roll forming.
• Customized sheet length, effective width, coating system, surface finish, and RAL colors can be arranged according to project requirements.
• Different corrugated profiles are available for roofing and wall applications.

6．Advantages

• The lightweight sheet structure supports easier handling and installation.
• The galvalume substrate with AZ coating improves outdoor corrosion resistance.
• The corrugated profile increases panel rigidity and water drainage performance.
• Multiple paint systems support different weather exposure conditions.
• Bright and matt surface finishes support different architectural requirements.
• Customized RAL colors provide appearance consistency for construction projects.

7．How to Choose

• Choose PE coating for standard roofing and wall cladding applications.
• Choose SMP or PVC coating for improved weather resistance.
• Choose PVDF coating for high UV, coastal, or long-term outdoor environments.
• Select thickness according to roof span, structural load, and wind resistance requirements.
• Confirm effective width, sheet length, color, and coating before production.

8．FAQ

Q1．What is this product used for
It is used for roofing, wall cladding, industrial buildings, warehouses, workshops, and prefabricated structures.

Q2．What coating systems are available
PE, SMP, PVC, and PVDF coating systems are available.

Q3．What color options can be supplied
RAL colors and customer sample colors are available.

Q4．What is the AZ coating range
The AZ coating range is 50–180g/m².

Q5．Can customized dimensions be produced
Yes. Customized effective width, sheet length, and corrugated profiles can be arranged according to project requirements.
