round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe

round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe

    • round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe
    • round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe
    • round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe
  • round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe

    Product Details:

    Place of Origin: China

    Payment & Shipping Terms:

    Packaging Details: standard export packing
    Delivery Time: Within 45 days after receive LC or TT
    Payment Terms: L/C, T/T
    Contact Now
    Detailed Product Description
    Commodity: Welded Steel Pipes / Pipe Grade: Q195, Q215, Q235, SPHC, SPCC,
    Round Thickness: 0.5-3.0mm Ellipse Thickness: 0.8-1.5mm
    High Light:

    welded stainless steel pipe

    ,

    stainless steel pipe fittings

    Round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe:

    Commodity

     Size

     Size tolerance(mm)

     Thickness(mm)

     Length Tolerance

      Circle Pipe

     Φ13~Φ25.4

      0.10

     0.5~1.5

     +50mm



     Φ18~Φ25.4

      0.10

     1.5~2.0

     +50mm



     Φ25.4~Φ34

      0.10

     0.7~2.0

     +50mm



     Φ25.4~Φ34

      0.12

     0.8~3.0

     +50mm



     Φ50.8~Φ79.2

      0.12

      1.0~3.0

     +50mm

      Square Pipe

     16×16~25.4x25.4

      0.15

      0.7~2.0

     +50mm



     30×30~50×50

      0.20

     1.0~3.0

     +50mm



     60×60

      0.15

     0.7~2.0

     +50mm



     100×100--200×200

      0.60

     3.0~6.0

     +50mm

     Rectangle Pipe

     10×20~20×40

      0.20

     0.8~1.5

     +50mm



     20×40~30×50

      0.25

     1.0~2.5

     +50mm



     25×70~38.1.76.2

      0.25

     1.2~2.5

     +50mm



     30×60~40x80

      0.30

     1.2~2.5

     +50mm



     120×60~150×250

      0.60

     3.0~6.0

     +50mm

      Ellipse Pipe

     Φ10~Φ20

      0.20

     0.8~1.5

     +50mm

    Steel Grade:  Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al etc.



    round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe 0
    round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe 1
    round / Ellipse Q195, Q215, Q235, SPHC, SPCC, 08Yu, 08Al Welded Steel Pipes / Pipe 2
