JIS G3101 SS400 Pre Galvanized and Hot Dipped Galvanized Steel C Channel

1．Product Overview

Galvanized steel C channel is widely used in building structures, cable support systems, photovoltaic mounting systems, mechanical frames, electrical installations, and industrial support structures.

The product is manufactured according to JIS G3101 SS400, ASTM A36, EN 10025 S275JR, GB700 Q235B, and Q345B standards. Both pre galvanized and hot dipped galvanized finishes are available for indoor and outdoor corrosion protection requirements.

2．Technical Solution

The C channel adopts hot rolled or formed steel substrate combined with zinc coating protection to improve corrosion resistance in humid, industrial, and outdoor environments.

Pre galvanized products with 60–275g/m² zinc coating are suitable for indoor structural applications and electrical support systems. Hot dipped galvanized products with coating over 450g/m² provide stronger corrosion resistance for outdoor infrastructure, coastal projects, and industrial installations.

Optional slotted hole configurations support flexible installation and connection requirements.

3．Specifications

4．Application

The galvanized C channel is used in cable tray systems, solar mounting structures, building frameworks, suspended supports, industrial equipment frames, warehouse systems, HVAC support structures, bridge engineering, and electrical installations.

5．Processing

The product supports punching, cutting, welding, galvanizing, assembly installation, and customized hole processing.

Customized slot spacing, hole type, and channel length can be supplied according to project installation requirements.

6．Advantages

• High corrosion resistance with galvanized surface
• Available in pre galvanized and hot dipped galvanized finishes
• Multiple thickness and size options for structural flexibility
• Suitable for indoor and outdoor support systems
• Optional slotted holes for fast installation
• Compatible with structural, solar, and electrical applications

7．How to Choose

• Choose pre galvanized C channel for indoor support systems and dry environments.
• Choose hot dipped galvanized products for outdoor, humid, coastal, or industrial conditions requiring stronger corrosion protection.
• Select thickness according to load-bearing requirements and support span.
• Confirm hole type and channel dimensions before production.

8．FAQ

Q1．What surface treatments are available
Pre galvanized and hot dipped galvanized finishes are available.

Q2．What zinc coating range can be supplied
Pre galvanized coating is 60–275g/m², and hot dipped galvanized coating is over 450g/m².

Q3．What sizes are available
Common sizes include 41×21mm, 41×41mm, 41×62mm, and 41×82mm.

Q4．Can channels be supplied without holes
Yes. Both slotted hole and no-hole configurations are available.

Q5．What is the MOQ
The minimum order quantity is 50 MT per size.
