Custom Cut DC01, DC02, DC03, DC04, SAE 1006, SAE 1008 Cold Rolled Steel Coils / Sheet

Custom Cut DC01, DC02, DC03, DC04, SAE 1006, SAE 1008 Cold Rolled Steel Coils / Sheet

1．Product Overview

Cold rolled steel coil and sheet are suitable for applications that require controlled thickness, stable width, and consistent surface condition for downstream blanking, bending, forming, and sheet fabrication. This product range covers general commercial grades as well as drawing-related grades, so the material can be selected according to the actual forming route.

The available size range covers 0.15–3.0mm thickness with widths of 750–1010mm, 1220mm, and 1250mm. The material can be supplied in coil form or converted to sheet length according to downstream processing requirement.

2．Technical Solution

The product is supplied under JIS, EN, DIN, GB, and SAE grade systems, which allows matching to different technical specifications and market requirements. Grade selection is the main basis for distinguishing general commercial use from drawing-related use.

For actual processing, the key factors are thickness range, width range, coil build, and grade type. Coil ID of 508mm or 610mm and maximum coil weight of 11 MT are suitable for common decoiling, leveling, slitting, and cut-to-length lines.

3．Specifications

4．Application

• This material is suitable for general sheet fabrication where cold rolled surface quality and dimensional control are required.
• It can be used for blanking, bending, forming, and drawing-related sheet processing according to grade selection.
• It is also suitable for coil-to-sheet conversion where sheet length is required by downstream users.

5．Processing

• The coil can be supplied for decoiling and cut-to-length production.
• It can be used for slitting and sheet conversion according to downstream width requirement.
• For general commercial processing, SPCC or DC01 grades are commonly selected.
• For drawing-related applications, SPCD, SPCE, DC03, or DC04 are more suitable choices.

6．Advantages

• The 0.15–3.0mm thickness range covers light to medium cold rolled coil processing requirements.
• The width range of 750–1010mm, 1220mm, and 1250mm matches mainstream sheet and coil processing lines.
• Multiple equivalent grade systems are available, which helps match different market and technical requirements.
• The product can be supplied in coil form and also converted to required sheet length.
• Coil ID of 508mm or 610mm and maximum coil weight of 11 MT support standard industrial handling and processing.

7．How to Choose

• Choose SPCC or DC01 for general commercial cold rolled applications.
• Choose SPCD, SPCE, DC03, or DC04 when better drawing performance is required.
• Choose thickness according to final part rigidity and forming route.
• Choose width according to blank layout, production efficiency, and downstream line requirement.
• Choose coil or cut sheet supply according to whether the customer uses decoiling lines or direct sheet processing.

8．FAQ

Q1．What is the thickness range of this cold rolled steel coil
The thickness range is 0.15–3.0mm.

Q2．What is the width range
The width range is 750–1010mm, 1220mm, and 1250mm.

Q3．What is the coil ID
The coil ID is 508mm or 610mm.

Q4．What is the maximum coil weight
The maximum coil weight is 11 MT.

Q5．Can the material be supplied as both coil and sheet
Yes. It can be supplied in coil form and can also be cut to required sheet length according to processing requirement.
