2348mm SPHC / ASTM A36 / SAE 1006 Hot Rolled Checkered Steel Plate, 1.5 - 40.0MM Thickness

2348mm SPHC / ASTM A36 / SAE 1006 Hot Rolled Checkered Steel Plate, 1.5 - 40.0MM Thickness

1．Product Overview

Hot rolled checkered steel plate is used where a raised surface pattern and a structural hot rolled base are both required in one product. Compared with plain hot rolled plate, the checkered surface provides better grip in walking and loading areas, while the plate thickness and steel grade remain the main factors for load capacity and fabrication performance.

This product range is suitable for custom cut supply, including 2348mm length and other project-based lengths up to 12000mm. It is intended for structural flooring, access platforms, ramps, fabricated tread sections, and other industrial steel parts that require both plate strength and anti-slip surface performance.

2．Technical Solution

The product is manufactured as hot rolled steel plate with a patterned top surface. In actual use, the steel grade controls the base strength, welding behavior, and forming route, while the raised surface pattern improves contact friction on the exposed side.

SPHC and SPHT-1 are generally selected when the route follows JIS hot rolled forming grades. ASTM A36 is suitable for general structural fabrication under ASTM practice. SAE 1006 and SAE 1008 are suitable where the project or downstream route follows SAE material logic. Q195, Q235, and Q345 can be selected according to GB-based strength and fabrication requirements.

For this type of product, plate thickness should be selected according to support spacing, service load, fabrication route, and installation condition rather than surface pattern alone.

3．Specifications

4．Application

• This material is suitable for structural flooring and access areas where a patterned surface is required.
• It can be used for platforms, ramps, stair-related fabricated parts, loading areas, equipment flooring, and industrial walkways.
• It is also suitable for cut structural panels, tread plates, and other fabricated steel parts used in general construction and industrial projects.

5．Processing

• The plate can be supplied in custom cut length according to project requirement.
• It is suitable for flame cutting, plasma cutting, drilling, welding, bending, and general structural fabrication.
• Thickness, width, and cut length should be selected together according to final part geometry, support condition, transport limit, and installation method.

6．Advantages

• The raised checkered surface improves grip compared with plain hot rolled plate.
• The thickness range of 1.5–40.0mm covers light, medium, and heavy plate applications.
• The width range from 1010mm to 2000mm supports mainstream structural plate layouts and wider fabricated parts.
• Custom cut lengths including 2348mm help match project-based fabrication and reduce secondary cutting.
• Multiple grade options allow the plate to be matched to different fabrication routes and project standards.

7．How to Choose

• Choose SPHC or SPHT-1 when the application follows JIS hot rolled sheet and plate logic.
• Choose ASTM A36 when the project follows ASTM structural steel routing.
• Choose Q195 for lighter general fabrication.
• Choose Q235 for standard structural and fabricated applications.
• Choose Q345 when higher strength level is required.
• Choose thickness according to load, support spacing, and required stiffness.
• Choose width and cut length according to blank layout, cutting yield, transport condition, and installation size.

8．FAQ

Q1．What is the thickness range of this hot rolled checkered steel plate
The thickness range is 1.5–40.0mm.

Q2．What widths are available
Available widths are 1010mm, 1220mm, 1250mm, 1500mm, 1800mm, and 2000mm.

Q3．Can the plate be supplied in 2348mm length
Yes. The plate can be supplied in 2348mm length and in other custom cut lengths up to 12000mm.

Q4．What grades are available
Available grades include SPHT-1, SPHC, ASTM A36, SAE 1006, SAE 1008, Q195, Q235, Q345, and ST12.

Q5．Is this product suitable for structural flooring
Yes. It is suitable for structural flooring, platforms, ramps, and other fabricated applications where a patterned surface is required.
